MF Pulse Bag Filter

Key words:Pulse Bag Filter,Bag Filter
Description:On the basis of MF-I spec, the square spec pulse dust filter with cloth bag MF- II is the amended and improved one.In addition to the advantages that I spec is high in the dust removing efficiency, big in the air capacity…
Order online
Details Photo Gallery

PRODUCT INTRODUCTION
On the basis of MF- I spec, the square spec pulse dust filter with cloth bag MF- II is the amended and improved one.

CHARACTERISTICS
In addition to the advantages that I spec is high in the dust removing efficiency, big in the air capacity , stable in the performance, easy in operation and maintenance, MC- II has the better result than MC- I. Such as: it is not easy to build up the powder and its application is wide and so on.

MATERIAL TO BE DRIED
The device is widely used for the ventilation, dust removing and powder restoration in the grain, food, feed, metallurgical, chemical, building material,medical and other industries.

Technical Parameter

Parameter Model
MF48 MF60 MF72 MF84 MF96 MF108 MF120
Area to be filterde (m2) 36.2 45.2 54.3 63.3 72.4 81.4 90.5
Quantity of filtering bag (Piece) 48 60 72 84 96 108 120
Filtered air amount of (m3/h) 6510-8680 8130-10840 9770-13000 11400-1520 13000-17370 14650-19530 16290-21700
Quantiyt of solenoid valve
(Piece)
8 10 12 14 16 18 20
Power (kw) 1.1 1.1 1.1 1.1 1.5 2.2 2.2
Bag size (mm) 120×2000
Speed of filtering air (m/min) 3-4
Ratio of air leakage (%) ≤5
Pressure of apraying and blowing (MPa) >0.4-0.6
Resistance of equipment (Pa) <1200
Efficiency of dust removing (%) ≥99.9(Can select suitable filtering material as per the powder characterisitic)


Technical Parameter

Parmeter Model
MF48 MF60 MF72 MF84 MF96 MF108 MF120
A 3530 3530 3530 3530 3530 3530 3530
B 3287 3287 3287 3287 3287 3287 3287
C 2552 2552 2552 2552 2552 2552 2552
D 1160 2260 1160 1160 1160 1160 1160
E 1350 1650 1950 2250 1350 2850 3150
F 1350 1350 1350 1350 1350 1350 1350
G 635 635 635 635 635 635 635
H 325 475 625 775 925 1075 1225
I 1586 1586 1586 1586 1586 1586 1586
J 790 790 790 790 850 850 850
K 824 824 824 824 824 824 824
M×N 400×500 500×500 600×500 700×600 700×600 800×600 800×600
P×Q 432×530 530×530 630×530 728×630 728×630 832×630 832×630
R×S 1050×1050 1350×1050 1650×1050 1950×1050 2250×1050 2250×1050 2850×1050
