ZLPG Chinese Herbal Medicine Extract Spray Dryer

Key words:Chinese Herbal Medicine Extract Spray Dryer,Spray Dryer
Description:The machine adopts full seal from.All parts are made of stainless steel.It is equipped with three grades of lter .The ltered air is one hundred thousand grades.The cooling device of wall is installed at the cylinder body…
Order online
Details Photo Gallery

DESCRIPTION
Chinese herbal medicine extract is refined from root, stem and leaves of plants, and contains high sugar especially from alcoholization process, which is easy melted at high temperature, Normal centrifugal spring cannot meet its drying requirement. For this reason, we have developed such a dryer especially used for Chinese herbal medicine extract on the basis of our experiences and tests. It has been popularized and used by some famous pharmaceutical manufacturers.


WORKING PRINCIPLE
After fresh air is filtered and heated, it enters into the air distributor which on the top of the drier. The hot air in spiral form equably enters into the drying room. When liquid raw material is passed through the high-speed centrifugal sprayer on the top of the tower, it will be rotated and sprayed into the extreme slim mist liquid beads. Raw material can be dried to the final products instantly while it contact with the heated air. Finished products are discharged continuously from bottom of the drying tower and cyclones segregator. Wasted air is discharged from the blower.


FEATURES
1.The tower is equipped with a cold air jacket;
2.The towers is equipped with automatic vibration device;
3.There are quick opening cleaning hole and sewage hole in the tower and piping system;
4.The dryer can be equipped with automatic control & thermostatic feeding tank;
5.Manual supplied accessories for the high-pressure washing system is available;
6.The material contacting area is constructed by stainless steel; (or use all stainless steel);
7.The material is collected by two-stage cyclone dust collector. Or use a cyclone operator and wet dust collector instead;
8.The inlet air temperature can be controlled by a continuous automatic control device.
9.The dryer can be equipped with gas cleaning device.

Spray Dryer for Chinese Medicine Extract


Technical Parameter

Item \ Model ZLPG-15 ZLPG-20 ZLPG-25 ZLPG-32 ZLPG-38 ZLPG-40 ZLPG-47 ZLPG-52 ZLPG-58
Evaporated amount of moisture (kg/h) 5 10 25 50 80 100 150 200 300
Treated amount of raw material liguid (kg/h) 6-7 12-14 25-34 50-68 80-108 100-135 150-203 200-270 300-406
Output of finished procuct (kg/h) 1-2 2-4 4.8-7.2 9.2-14 14.8-22.4 18.4-28 28-42 36.8-56.4 55-85
Solid content of damp raw material (%) 18-25
Ratio of moisture of finished product (%) 3-5
Electric power (kw) 36 45 63 99 132 153 204 246 330
Heating source steam plus electricity
Colleting way of product and its efficiency two-grade cyclone duster of one-grade cyclone duster and one-grade damp duster ≥95%
Automatic control meters and instruments indicator of temperature of hot air and humidity of air exhaust
Temperature of air in 150-200
Temperature of air out 80-100
Overal dimensions (mm) L 5000 5500 7000 8000 9800 11000 12200 14100 15000
W 3000 3500 4000 5000 5700 6200 7000 7800 9000
H 4500 4600 5200 6500 7600 8100 9000 9850 11100

Note:*The actual diamensions are in accordance with the customer’s requirement,the above dimensions are only for reference.
* The above is the largest evaporation.
